GEM-FLOW, G75-S, Electric, 2″ 2 Way NC
GEM-FLOW, G75-S, Electric, 2" 2 Way NC
Technical Specifications
- Function: 2 Way NC (Normally Closed)
- Ports size: 2″ BSPT
- Pressure range: 0.3 to 10 bar
- Temperature range: Fluid: 5ºC to 50ºC (no freezing), Ambient: -10ºC to 50ºC
- Solenoid:
- G75, 2W NC for all voltages.
- Available in AC, DC, and Latch types.
- Coil voltage: All Baccara coil voltages are ± 10% of nominal.
Construction Material
- Manual override: Plastic (Reinforced Nylon)
- Main Valve: Plastic (Reinforced Nylon)
- Solenoid Operator: Stainless Steel AISI 300 & 400
- Diaphragm: NR (Natural Rubber)
- Seals: NBR (Nitrile Butadiene Rubber)
- Spring: Stainless Steel AISI 300 series
